AMAT Applied Materials 0100-00008断路器组件

1.产 品 资 料 介 绍：

核心规格

功能与优势

• 多重保护：热磁复合脱扣，兼顾过载与短路防护，确保设备安全。
• 状态反馈：可配辅助 / 报警触头，便于 PLC 或 HMI 实时监测断路器状态。
• 远程控制：支持分励脱扣，可实现远程分闸，提升自动化水平。
• 高可靠性：工业级外壳与触点材料，适应频繁分合与恶劣环境。
• 安装便捷：标准导轨安装，互换性强，可快速替换。

安装与维护要点

1. 选型匹配
   • 根据负载电流、电压及分断能力选择合适额定值，确保保护可靠。
2. 安装固定
   • 使用 35 mm 导轨或面板螺丝紧固，确保接触良好。
3. 接线连接
   • 按端子标识接入主回路与控制回路，注意相序与极性。
4. 调试检查
   • 手动分合测试动作是否正常，测量接触电阻与绝缘电阻。
5. 维护保养
   • 每 6–12 个月检查触点磨损与螺丝紧固度，清洁外壳，防止灰尘堆积。

AMAT Applied Materials 0100-00008断路器组件 英文资料：

e777乐彩线路检测AMAT 0100-00008 is a circuit breaker component designed by Applied Materials for low-voltage distribution and control circuits in semiconductor equipment. It is used to automatically cut off power in case of overcurrent, short circuit, undervoltage and other abnormalities, protecting critical components and operators. It is commonly used in control stations and subsystems on platforms such as Centura and Endura.

e777乐彩线路检测Core specifications

Project specifications/characteristics remarks

e777乐彩线路检测Types of miniature circuit breakers (MCCBs) or modular circuit breakers may include thermal magnetic release and auxiliary contacts

e777乐彩线路检测Rated voltage 240 VAC (typical) compatible with 220-240 VAC industrial power supply

Rated current 5-30 A (customizable) according to load configuration

e777乐彩线路检测The breaking capacity is 1000-1500 A (AC 240 V) to meet the transient current surge of the equipment

Release characteristics: Overload long delay+Short circuit instantaneous fast response and stable protection

Polar 1P/2P (optional) single/double line system

e777乐彩线路检测Auxiliary functions include auxiliary contacts, alarm contacts, and expandable remote disconnection and status monitoring for shunt release

e777乐彩线路检测Working temperature -20~+60 ℃, wide temperature industrial environment

Installation method: Standard 35mm guide rail or panel fixed for easy maintenance and replacement

e777乐彩线路检测Certified CE, UL, RoHS compliant with international safety standards

Features and advantages

Multiple protection: Thermal magnetic composite release, balancing overload and short circuit protection to ensure equipment safety.

Status feedback: Can be equipped with auxiliary/alarm contacts for real-time monitoring of circuit breaker status by PLC or HMI.

Remote control: supports shunt tripping, can achieve remote disconnection, and improve automation level.

High reliability: Industrial grade casing and contact materials, suitable for frequent opening and closing and harsh environments.

e777乐彩线路检测Easy installation: Standard rail installation, strong interchangeability, and quick replacement.

e777乐彩线路检测Key points for installation and maintenance

Selection matching

ｓｅｌｅｃｔ appropriate rated values based on load current, voltage, and breaking capacity to ensure reliable protection.

e777乐彩线路检测install and fix

e777乐彩线路检测Secure with 35mm guide rails or panel screws to ensure good contact.

e777乐彩线路检测Wiring connection

Connect the main circuit and control circuit according to the terminal identification, paying attention to the phase sequence and polarity.

Debugging and inspection

Check if the manual opening and closing test is normal, measure the contact resistance and insulation resistance.

maintenance

Check contact wear and screw tightness every 6-12 months, clean the casing to prevent dust accumulation.
