AMAT Applied Materials  0500-01065 接口模块

1.产 品 资 料 介 绍：

核心规格

功能特点

• 多协议兼容：可适配不同品牌 PLC / 控制器，通用性强。
• 模块化通道：通道可灵活配置，便于扩展与维护。
• 状态可视化：每路配备 LED 指示灯，实时显示工作状态。
• 热插拔设计：带电更换模块，减少停机时间。
• 低噪声设计：多层 PCB + 屏蔽设计，抑制串扰与噪声干扰。

典型应用

• 300 mm 晶圆 Load Lock 腔室控制与状态监测
• 半导体设备晶圆传输系统信号分配
• 工业自动化中传感器与执行器信号转接

AMAT Applied Materials 0500-01065 接口模块 英文资料：

AMAT Applied Materials 0500-01065 is a 300 mm wafer load lock interface module PCB used to connect machine control systems with mechanical/pneumatic components, achieve signal conversion, isolation, and distribution, and is compatible with multiple generations of 300 mm platforms.

e777乐彩线路检测Core specifications

Project specification remarks

e777乐彩线路检测Application Series: Buffer Chamber for 300mm Load Lock Wafer Entry and Exit Equipment

e777乐彩线路检测Functional signal conversion and isolation control, sensors, pneumatic valves, etc

e777乐彩线路检测Interface type: high-density needle socket, connector (Phoenix/TE) compatible with backplate and field devices

Working voltage 5-24 VDC (multi rail) supports mixed voltage distribution

e777乐彩线路检测Isolation method: photoelectric isolation+electrical isolation. Each circuit is independent and has strong anti-interference ability

Installation method: panel type/rail type standard cabinet adaptation

e777乐彩线路检测Size 160 × 100 × 40 mm (approximately) Compact design

Protection level IP20 dustproof and splash proof

Features

Multi protocol compatibility: can adapt to different brands of PLCs/controllers, with strong universality.

e777乐彩线路检测Modular channel: The channel can be flexibly configured for easy expansion and maintenance.

Status visualization: Each channel is equipped with LED indicator lights to display the working status in real-time.

e777乐彩线路检测Hot swappable design: ｒｅｐｌａｃｅ modules with power on to reduce downtime.

Low noise design: multi-layer PCB+shielding design to suppress crosstalk and noise interference.

Typical Applications

e777乐彩线路检测300 mm wafer load lock chamber control and status monitoring

Signal distribution for semiconductor equipment wafer transmission system

Signal conversion between sensors and actuators in industrial automation

AMAT Applied Materials  0500-01065 接口模块 e777乐彩线路检测
