AMAT Applied Materials 903172-001输入输出模块
1.产 品 资 料 介 绍：
参数类别 | 规格说明 |
物理规格 | 重量约 5.5 lbs，尺寸约 12.5in×8.2in×3.0in（符合工业标准 PCB 板卡封装） |
I/O 通道配置 | 预计含 6 路数字输入、4 路数字输出，可能兼容 2 路模拟量通道（适配液体流量 / 压力信号） |
工作环境 | 温度范围 - 20°C 至 80°C，湿度 0-95% 无冷凝（满足半导体洁净车间环境要求） |
供电与隔离 | 支持 110-240V AC 宽压供电，具备 I/O、电源、网络三重电路隔离（防干扰设计） |
认证标准 | 符合 CE、UL、RoHS 认证（工业级模块通用合规要求） |
- 核心应用领域
- 液体源液位、压力信号的实时采集
- 电磁阀、泵体等执行机构的开关控制
- 故障状态的快速反馈与安全联锁
AMAT Applied Materials 903172-001输入输出模块 英文资料：
1、 Product core positioning
AMAT 903172-001 is a Liquid Source I/O PCB board launched by Applied Materials. It is a key control component of semiconductor manufacturing equipment, mainly responsible for signal acquisition and instruction execution of liquid source systems. Its design is deeply compatible with subsystems such as liquid transportation and source material control in AMAT semiconductor production lines, and is the core interface module that ensures process stability.
2、 Key technical parameters (derived from the characteristics of similar modules in the industry)
Based on the general specifications of AMAT industrial modules and the technical standards for discrete I/O modules, the core parameters of this module are estimated as follows:
Parameter category
Specification Description
e777乐彩线路检测Physical specifications
Weight approximately 5.5 lbs, size approximately 12.5in x 8.2in x 3.0in (compliant with industry standard PCB board packaging)
I/O channel configuration
Expected to include 6 digital inputs and 4 digital outputs, possibly compatible with 2 analog channels (suitable for liquid flow/pressure signals)
Working environment
e777乐彩线路检测Temperature range -20 ° C to 80 ° C, humidity 0-95%, no condensation (meets the requirements of semiconductor clean room environment)
Power supply and isolation
Supports 110-240V AC wide voltage power supply, with triple circuit isolation for I/O, power supply, and network (anti-interference design)
Certification standards
Compliant with CE, UL, RoHS certifications (general compliance requirements for industrial grade modules)
3、 Application scenarios and adaptation systems
Core application areas
As a liquid source I/O board, it is mainly used for chemical vapor deposition (CVD), atomic layer deposition (ALD) and other process equipment in semiconductor manufacturing. It is responsible for connecting liquid source storage tanks, flow controllers, valves and other terminal devices to achieve:
e777乐彩线路检测Real time acquisition of liquid level and pressure signals from liquid sources
Switching control of actuators such as solenoid valves and pump bodies
e777乐彩线路检测Rapid feedback of fault status and safety interlock
AMAT Applied Materials 903172-001输入输出模块 e777乐彩线路检测
