SCHNEIDER MX-XF/SHT-SHC 电压线圈

1.产 品 资 料 介 绍：

中文资料：

施耐德 MX-XF/SHT-SHC 电压线圈e777乐彩线路检测 是一种专为工业断路器或开关设备设计的附件组件，通常用于远程控制和断路器的保护操作。以下是关于该电压线圈的详细信息：

主要功能

1. MX-XF (分励脱扣线圈)：

   • 用于远程断开断路器。
   • 接收到电压信号时，触发断路器跳闸，切断电源。
   • 通常用于紧急停机或保护性脱扣。

2. SHT-SHC (欠压脱扣线圈)：

   • 用于监控电源电压状态。
   • 如果电压低于设定值（欠压条件），自动触发断路器跳闸。
   • 用于防止设备在不稳定的电压条件下运行，确保安全。

技术参数

英文资料：

Schneider MX-XF/SHT-SHC voltage coil is an accessory component designed specifically for industrial circuit breakers or switchgear, typically used for remote control and circuit breaker protection operations. The following is detailed information about the voltage coil:

e777乐彩线路检测major function

MX-XF (shunt trip coil):

Used for remote disconnection of circuit breakers.

When receiving a voltage signal, trigger the circuit breaker to trip and cut off the power supply.

e777乐彩线路检测Usually used for emergency shutdown or protective tripping.

SHT-SHC (undervoltage trip coil):

Used to monitor the voltage status of the power supply.

If the voltage is lower than the set value (under voltage condition), the circuit breaker will automatically trip.

e777乐彩线路检测Used to prevent equipment from operating under unstable voltage conditions and ensure safety.

e777乐彩线路检测technical parameter

Detailed parameter information

The rated voltage range is AC or DC voltage, usually in various specifications such as 24V, 48V, 110V, 220V, etc

Action time is usually ≤ 50 ms

e777乐彩线路检测The power consumption varies depending on the coil model and voltage, about 3-8 W

e777乐彩线路检测Installation position: Installed inside the circuit breaker or in the accessory slot

Operating temperature range -25 ° C to+70 ° C

e777乐彩线路检测Compatible with Schneider electrical circuit breakers (such as NSX series, Masterpact, etc.)

Durable mechanical and electrical lifespan are both high, suitable for frequent operation needs

e777乐彩线路检测Control signal standard voltage signal input
