AMAT Applied Materials  0100-11000分析输入板

1.产 品 资 料 介 绍：

AMAT Applied Materials  0100-11000分析输入板 英文资料：

1、 Core positioning

AMAT 0100-11000 is the "data acquisition core" of semiconductor equipment analysis and detection systems, designed specifically for high-precision reception of analog/digital signals from mass spectrometers, spectrometers, and sensors (such as temperature and pressure). Through built-in signal conditioning circuits, it achieves data noise reduction, amplification, and standardization conversion, adapts to Class 10 clean environments and low signal interference requirements, and provides precise data support for process analysis and quality control.

e777乐彩线路检测2、 Key parameters

Category

e777乐彩线路检测Specifications

e777乐彩线路检测Signal input

12 analog inputs (0-10V/4-20mA), 8 digital inputs (24V DC)

e777乐彩线路检测Collection accuracy

e777乐彩线路检测Analog input ± 0.05% FS, sampling rate ≤ 1kHz

Signal processing

e777乐彩线路检测Integrated 16 bit ADC converter, supporting digital filtering and signal amplification (gain adjustable from 1-100)

e777乐彩线路检测Environmental adaptation

e777乐彩线路检测-5-60 ℃, humidity<80%, anti EMI interference (EN 61000-6-2)

Security features

Input overvoltage protection (≤ 30V DC), reverse connection protection

e777乐彩线路检测Compatibility

Compatible with AMAT 0100-66025 control module, 03-81830-00 PCB, 0190-09445 detector

3、 Core applications

Analysis equipment data collection: Receive ion signals from wafer composition analysis mass spectrometer and light intensity signals from thin film thickness detection spectrometer, convert them into standard data, and transmit them to the control module.

Process environment monitoring: Collect signals from reaction chamber temperature, vacuum pressure, and gas concentration sensors, provide real-time feedback on the process environment status, and assist the control module in optimizing parameters.

Fault diagnosis data support: Record key signal fluctuations during equipment operation (such as RF power feedback and current signals), providing data basis for equipment fault tracing and preventive maintenance.

e777乐彩线路检测4、 Key points of operation and maintenance

e777乐彩线路检测Installation: Compatible with the 0100-02839 rack component standard card slot, the signal line adopts twisted pair shielded wire (single end grounded, grounding resistance ≤ 0.5 Ω), away from the RF module and high-voltage components.

e777乐彩线路检测Maintenance: Clean the gold fingers and wiring terminals every 3 months (using isopropanol dust-free cloth); Calibrate the collection accuracy every 6 months (using a standard signal source); Prioritize troubleshooting for input signal short circuits and aging filtering capacitors.

Procurement: Prioritize the selection of original suppliers (such as Changxin Automation and Semicar Electronics), verify the ADC conversion accuracy report and signal compatibility test report upon arrival, and ensure compatibility with existing analytical equipment.
