Motorola MVME 167-32A单板计算机

1.产 品 资 料 介 绍：

核心规格

功能亮点

• 高性能与多任务：33 MHz 68040 配合 FPU，支持 VxWorks、OS‑9 等实时操作系统，可满足多任务与高速数据处理需求。
• VME 总线兼容：全功能 32 位 VME 主 / 从接口，支持 D64 与本地总线突发传输，可与 MVME 系列处理器、I/O 及通信模块无缝集成。
• 丰富 I/O 资源：4 串口、1 并口、SCSI 与以太网接口，便于连接外部设备、存储及网络，实现远程监控与数据传输。
• 高可靠性设计：ECC 内存、硬件 Watchdog、电池备份时钟及抗干扰设计，适应工业、科研及国防等恶劣环境。
• 模块化与扩展能力：支持通过扩展板和适配器灵活扩展功能，便于系统升级与维护。

典型应用

• 工业自动化控制系统
• 电力与能源远程监控
• 交通运输信号系统
• 国防与航空航天数据处理
• 科研实验设备高带宽数据采集

Motorola MVME 167-32A单板计算机 英文资料：

e777乐彩线路检测MVME 167-32A is a VME bus dual high single board computer based on Motorola 68040 processor, with a working frequency of 33MHz and onboard 8MB ECC protected DRAM. It has rich I/O interfaces and industrial grade reliability, and is suitable for real-time control, data acquisition, and communication processing tasks.

e777乐彩线路检测Core specifications

Project specifications

e777乐彩线路检测Processor Motorola MC68040, 33MHz, including MMU and FPU

Memory 8   MB 32-bit DRAM, ECC protection, expandable up to 256   MB

Storage interface SCSI bus, supports DMA high-speed transfer

Network interface board with Ethernet transceiver interface, supporting DMA

Four EIA 232-D serial ports, supporting DMA

Parallel port 1 Centronics compatible bidirectional port

e777乐彩线路检测Timer 4 32-bit timers+1 Watchdog

Real time clock 8 KB NVRAM with battery backup

e777乐彩线路检测Indicator lights FAIL, STAT, RUN, SCON, LAN,+12V, SCSI, VME

Power supply+5   Vdc (± 5%), typical 5.0   A, maximum 6.5   A;+12   Vdc maximum 100   mA; -12   Vdc maximum 100   mA

e777乐彩线路检测Working temperature 0-55 ℃ (forced air cooling)

e777乐彩线路检测Mechanical dimension double height VME module

e777乐彩线路检测Key Features

High performance and multitasking: The 33 MHz 68040, combined with FPU, supports real-time operating systems such as VxWorks and OS-9, meeting the needs of multitasking and high-speed data processing.

VME bus compatibility: Fully functional 32-bit VME master/slave interface, supporting D64 and local bus burst transmission, seamlessly integrated with MVME series processors, I/O and communication modules.

Rich I/O resources: 4 serial ports, 1 parallel port, SCSI and Ethernet interfaces, convenient for connecting external devices, storage and networks, enabling remote monitoring and data transmission.

e777乐彩线路检测High reliability design: ECC memory, hardware Watchdog, battery backup clock, and anti-interference design, suitable for harsh environments such as industry, scientific research, and national defense.

e777乐彩线路检测Modularity and scalability: Supports flexible expansion of functions through expansion boards and adapters, facilitating system upgrades and maintenance.

Typical Applications

industrial automation control system

Remote monitoring of electricity and energy

Transportation Signal System

e777乐彩线路检测Defense and Aerospace Data Processing

High bandwidth data acquisition for scientific research experimental equipment

MVME 167-32A is suitable for real-time embedded systems that require high performance, reliability, and scalability, especially for critical task scenarios that require long-term stable operation in harsh environments.

Motorola MVME 167-32A单板计算机  产      品      展      示

 产品视频
