Motorola MPC750 SCT750 EO-00102 印刷电路板

1.产 品 资 料 介 绍：

Motorola MPC750 SCT750 EO-00102 单板计算机

核心特点

• 架构：PowerPC 32 位，高性能浮点运算
• 接口：VME 总线，支持主从模式
• 性能：200-366 MHz 时钟频率
• 存储：DRAM 主存 + Flash/ROM 固件存储
• 扩展：可能具备 PCI / 局部总线接口
• 可靠性：工业 / 电信级设计，适合长期运行

应用场景

• 工业自动化：生产线控制与设备管理
• 通信设备：早期电信交换机与网络节点
• 测试测量：高速数据采集与处理系统
• 嵌入式控制：支持 VxWorks、pSOS 等 RTOS

产品优势

• 高性能：PowerPC 架构带来卓越运算效率
• 模块化：VME 框架内可灵活组合功能板
• 可靠性：满足严苛环境下的长时间运行
• 扩展性：通过背板与局部总线连接丰富外设

技术规格推测

• 集成一级指令 / 数据缓存
• 支持 JTAG 调试接口
• 内置定时器与中断控制器
• 设计符合工业温度范围要求

Motorola MPC750 SCT750 EO-00102 印刷电路板英文资料：

Motorola MPC750 SCT750 EO-00102 Single Board Computer

This is a VME bus single board computer based on PowerPC MPC750 processor, suitable for industrial control, testing and measurement, and embedded computing platforms.

e777乐彩线路检测Core Features

e777乐彩线路检测Architecture: PowerPC 32-bit, high-performance floating-point operation

e777乐彩线路检测Interface: VME bus, supports master-slave mode

Performance: 200-366 MHz clock frequency

Storage: DRAM main memory+Flash/ROM firmware storage

Expansion: May have PCI/local bus interface

Reliability: Industrial/telecommunications grade design, suitable for long-term operation

e777乐彩线路检测Application scenarios

Industrial Automation: Production Line Control and Equipment Management

e777乐彩线路检测Communication equipment: early telecommunications switches and network nodes

e777乐彩线路检测Test measurement: High speed data acquisition and processing system

Embedded Control: Supports RTOS such as VxWorks and pSOS

Product advantages

High performance: PowerPC architecture brings excellent computing efficiency

Modularization: Flexible combination of functional boards within the VME framework

Reliability: Meets long-term operation in harsh environments

Scalability: Rich peripherals connected through backplane and local bus

e777乐彩线路检测Technical specification speculation

e777乐彩线路检测Integrated Level 1 Instruction/Data Cache

Support JTAG debugging interface

e777乐彩线路检测Built in timer and interrupt controller

Design to meet the requirements of industrial temperature range
