GE 193X638AAC06电动电路板
1.产 品 资 料 介 绍：
中文资料：
GE 193X638AAC06 是通用电气（General Electric）193X 系列中的一款重要控制模块，常被称作电动电路板（Motor Control Board）。该模块专为 GE 工业控制系统中的驱动与调速应用设计，用于处理电机的启动、运行、调速、停机及保护等功能。其适用于中大型工业设备中的 DC 或 AC 电机控制系统，广泛部署在发电厂、冶金、石化等自动化场景中。
技术参数与功能特点
产品型号：193X638AAC06
产品名称：电动电路板 / Motor Control Board
系列归属：GE 193X 模块化控制系统
主要功能：
e777乐彩线路检测电机控制信号处理（启停/加减速）
e777乐彩线路检测控制信号放大、隔离与驱动
电流/电压反馈逻辑处理
e777乐彩线路检测启动/停止逻辑判断与控制
e777乐彩线路检测故障检测（如过流、欠压）逻辑保护
信号接口类型e777乐彩线路检测：TTL/CMOS逻辑、电压/电流模拟信号
控制方式支持：闭环调速控制 / 开环逻辑控制
电源输入：+5V、±15V DC（由系统供电）
板载元件e777乐彩线路检测：逻辑电路、驱动电路、比较器、继电器、电容电阻组、接口接线排等
工作温度范围e777乐彩线路检测：-20°C ～ +70°C
安装方式：插槽式，金手指接口，适配GE控制系统背板
外形尺寸：符合193X标准卡件规格，便于模块化安装与维护
指示功能：板载LED灯用于运行/故障状态指示
功能作用
电动机逻辑控制：管理电机的启动、运行、停止流程，并配合执行机构如接触器/驱动器控制信号。
速度控制逻辑e777乐彩线路检测：根据反馈信号调节输出，实现稳速运行或加/减速控制。
电气信号处理e777乐彩线路检测：接收上位系统信号并进行变换、放大、驱动等操作。
系统联动接口e777乐彩线路检测：与其他模块（如统计板、过渡板、报警板等）联动完成系统逻辑闭环。
故障检测与反馈：可对电流、电压、温度等参数进行检测并输出故障报警信号。
英文资料：
GE 193X638AAC06 is an important control module in the General Electric 193X series, often referred to as the Motor Control Board. This module is designed specifically for drive and speed regulation applications in GE industrial control systems, used to handle functions such as motor start-up, operation, speed regulation, shutdown, and protection. It is suitable for DC or AC motor control systems in medium to large industrial equipment and widely deployed in automation scenarios such as power plants, metallurgy, and petrochemicals.
e777乐彩线路检测Technical parameters and functional characteristics
e777乐彩线路检测Product model: 193X638AAC06
e777乐彩线路检测Product Name: Electric Circuit Board/Motor Control Board
Series affiliation: GE 193X modular control system
Main functions:
e777乐彩线路检测Motor control signal processing (start stop/acceleration/deceleration)
Control signal amplification, isolation, and driving
Current/voltage feedback logic processing
e777乐彩线路检测Start/stop logic judgment and control
e777乐彩线路检测Fault detection (such as overcurrent and undervoltage) logic protection
e777乐彩线路检测Signal interface type: TTL/CMOS logic, voltage/current analog signal
Control mode support: closed-loop speed control/open-loop logic control
Power input:+ 5V, ± 15V DC (powered by the system)
Onboard components: logic circuit, driver circuit, comparator, relay, capacitor resistor group, interface wiring block, etc
Working temperature range:- 20°C ～ +70°C
Installation method: slot type, gold finger interface, compatible with GE control system backplane
e777乐彩线路检测Dimensions: Compliant with 193X standard card specifications, convenient for modular installation and maintenance
Indication function: Onboard LED lights are used for operation/fault status indication
function
e777乐彩线路检测Motor logic control: manages the starting, running, and stopping process of the motor, and cooperates with the executing mechanism such as contactors/drivers to control signals.
e777乐彩线路检测Speed control logic: Adjust the output based on feedback signals to achieve stable speed operation or acceleration/deceleration control.
Electrical signal processing: Receive signals from the upper system and perform operations such as transformation, amplification, and driving.
System linkage interface: It links with other modules (such as statistical board, transition board, alarm board, etc.) to complete the system logic loop.
Fault detection and feedback: It can detect parameters such as current, voltage, temperature, etc. and output fault alarm signals.
