AMAT Applied Materials 64-81813-00显示PCB板

1.产 品 资 料 介 绍：

核心规格与参数

主要功能模块

1. LVDS 信号处理：接收主控制器的 LVDS 图像数据，进行阻抗匹配与信号整形，支持 18/24 位色深，确保高分辨率图像无失真显示。
2. 触摸控制电路：采用电容式触摸控制器，通过 USB 接口与主系统通信，支持单点或多点触摸（依屏幕而定）。
3. 电源管理模块：输入 12V/24V，输出 5V（给屏逻辑）、12V（背光），具备过压、欠压、短路保护功能。
4. 背光驱动电路：提供 PWM 调光接口，可调节屏幕亮度，并支持背光开启 / 关闭控制。
5. 状态指示与保护：设有电源、背光、触摸状态指示灯，方便现场维护与故障排查。

AMAT Applied Materials 64-81813-00显示PCB板 英文资料：

AMAT 64-81813-00 is a 12.1-inch industrial touch screen display driver PCB customized for an application materials company. It is compatible with HMI operation panels for wafer manufacturing equipment such as Centura and Endura, and integrates LVDS signal processing, touch control, power management, and status indication functions. It supports a resolution of 1024 × 768 and can work stably in high-purity and strong electromagnetic interference environments in semiconductor workshops.

Core specifications and parameters

Project specifications/indicators description

e777乐彩线路检测Function positioning display driver+touch control+power management driver 12.1 "industrial screen and processing touch signals, integrated 5V/12V power conversion and status indication

Compatible with AMAT original screens and third-party screens that comply with VESA standards, the 12.1 "industrial touch screen (4:31024 × 768) is compatible

e777乐彩线路检测Interface type input: LVDS x 1, USB (touch) x 1 DC 12V/24V； Output: Backlight control signal supports single/dual channel LVDS, USB touch interface compatible with HID protocol

Material and protective substrate: FR-4; Surface treatment: Lead free hot air leveling (HASL) or chemical nickel/immersion gold (ENIG) meets IPC Class 2 industrial manufacturing standards and is suitable for workshop cleaning and maintenance environments

e777乐彩线路检测Size and installation: 245 × 180mm, 4 M4 mounting holes, hole spacing of 240 × 175mm, suitable for AMAT standard operation panel installation position

The working environment temperature ranges from 0 to 55 ℃; Humidity ≤ 85% RH (no condensation), anti electromagnetic interference capability in accordance with EN 61000-6-2 standard

e777乐彩线路检测Electrical characteristic power consumption ≤ 10W (excluding screen); LVDS impedance of 100 Ω± 10% supports 100MHz high-speed differential signal transmission, ensuring image stability

Main functional modules

e777乐彩线路检测LVDS signal processing: Receive LVDS image data from the main controller, perform impedance matching and signal shaping, support 18/24 bit color depth, and ensure distortion free display of high-resolution images.

e777乐彩线路检测Touch control circuit: Adopting a capacitive touch controller, it communicates with the main system through a USB interface and supports single or multi-point touch (depending on the screen).

e777乐彩线路检测Power management module: Input 12V/24V, output 5V (screen logic), 12V (backlight), with overvoltage, undervoltage, and short-circuit protection functions.

Backlight driver circuit: Provides PWM dimming interface, adjustable screen brightness, and supports backlight on/off control.

Status indication and protection: equipped with power supply, backlight, and touch status indicator lights, convenient for on-site maintenance and troubleshooting.

 AMAT Applied Materials 64-81813-00显示PCB板 e777乐彩线路检测
