AMAT Applied Materials 0021-07089夹盖组件

1.产 品 资 料 介 绍：

AMAT Applied Materials 0021-07089 夹盖组件

一、核心规格与技术参数

二、核心组件与功能

1. 机械卡扣单元：4 个对称分布的不锈钢卡扣，通过气动驱动实现 “扣合 - 解锁” 动作，确保顶盖与腔室法兰紧密贴合，避免真空环境下顶盖位移。
2. 密封垫圈组件：主密封圈（FFKM）嵌入夹盖内侧凹槽，与腔室法兰面紧密接触形成真空密封；辅助密封圈（FKM）用于隔绝外部粉尘、水汽，保护主密封区域。
3. 气动控制模块：含小型气动缸、电磁阀与压力传感器，可实时监测夹持气压（通常 0.4~0.6 MPa），气压不足时触发报警，防止密封失效。
4. 位置检测单元：集成光电传感器，检测夹盖 “完全闭合”“完全打开” 状态，信号反馈至设备主控制器，确保自动化流程（如腔室抽真空、工艺启动）的逻辑安全。

AMAT Applied Materials 0021-07089夹盖组件 英文资料：

e777乐彩线路检测AMAT Applied Materials 0021-07089 Clamp Cover Component

e777乐彩线路检测AMAT 0021-07089 is a vacuum sealed clamping cover component designed specifically for semiconductor equipment process chambers. Its core function is to achieve precise clamping, sealing, and rapid opening and closing of the process chamber top cover. It is compatible with vacuum process chambers such as Centura and Endura platforms for etching and thin film deposition, ensuring the sealing reliability and operational convenience of the chamber in high vacuum and strong corrosive environments.

1、 Core specifications and technical parameters

e777乐彩线路检测Detailed description of project specifications/indicators

Functional positioning: Vacuum chamber top cover clamping+sealing combines mechanical clamping fixation and vacuum sealing to prevent chamber vacuum leakage

Compatible with core process chambers such as AMAT etching chambers (e.g. Etch Chamber) and PECVD deposition chambers, with a diameter of 300 mm/200 mm (mainstream specifications)

Sealing grade leakage rate ≤ 1 × 10 ⁻⁹ Pa · m ³/s meets the requirements of semiconductor processes for high vacuum environments (chamber working vacuum degree is usually 10 ⁻³~10 ⁻⁹ Pa)

Sealing material: main sealing ring: perfluoroether rubber (FFKM); Auxiliary sealing: FKM FFKM is resistant to chemical corrosion (able to withstand plasma, acid and alkali process gases) and high temperature (long-term working temperature -20~200 ℃), avoiding seal failure caused by aging of the sealing ring

The clamping structure consists of a 4-point mechanical buckle and a pneumatic drive buckle made of stainless steel 316L material (corrosion-resistant). The buckle is opened and closed by a pneumatic cylinder, and the clamping force can be adjusted (rated clamping force 500~800 N) to ensure even force distribution on the top cover

Fully open/close time ≤ 15 seconds, in conjunction with equipment automation processes, to shorten downtime for chamber maintenance (such as component replacement, cleaning)

e777乐彩线路检测Working environment temperature -10~80 ℃; Resistant to plasma and process gas corrosion, suitable for highly corrosive and dusty process environments around the chamber. The surface of the components is passivated (such as electrolytic polishing) to reduce the adhesion of process residues

e777乐彩线路检测2、 Core components and functions

e777乐彩线路检测Mechanical buckle unit: 4 symmetrically distributed stainless steel buckles, which achieve the "buckle unlock" action through pneumatic drive, ensuring a tight fit between the top cover and the chamber flange, and avoiding displacement of the top cover under vacuum environment.

Sealing gasket component: The main sealing ring (FFKM) is embedded in the groove on the inner side of the clamp cover, tightly contacting the chamber flange surface to form a vacuum seal; The auxiliary sealing ring (FKM) is used to isolate external dust and water vapor, and protect the main sealing area.

Pneumatic control module: includes a small pneumatic cylinder, solenoid valve, and pressure sensor, which can monitor the clamping pressure in real time (usually 0.4~0.6 MPa), trigger an alarm when the pressure is insufficient, and prevent seal failure.
