AMAT Applied Materials 0100-09126远程配线板
1.产 品 资 料 介 绍：
核心功能
技术参数
典型应用
AMAT Applied Materials 0100-09126远程配线板 英文资料：
AMAT Applied Materials 0100-09126 Remote Distribution Board is a high-density multiplexer board that supports remote centralized distribution and management of digital, analog, and power signals. It is widely used in semiconductor manufacturing equipment and industrial automation control systems.
core functionality
e777乐彩线路检测Remote signal distribution: Extend the main controller signal to multiple remote modules to achieve long-distance and multi-point transmission
e777乐彩线路检测Isolation protection: using photoelectric/electrical isolation to prevent interference and signal crosstalk
Modular design: Channels can be flexibly configured for easy expansion and maintenance
e777乐彩线路检测Status monitoring: equipped with LED indicator lights, real-time display of channel working status
Hot swappable support: Supports live module replacement to reduce downtime
e777乐彩线路检测Protective treatment: surface coated with moisture-proof and anti-corrosion coatings, suitable for harsh industrial environments
Technical Specifications
e777乐彩线路检测Project specifications
e777乐彩线路检测Number of channels 16-32 (customizable)
Working voltage 24VDC (± 10%)
Isolation level: 2.5kVrms between signals, 5kVrms between power supply and signals
Working temperature -10 ℃~60 ℃
6-8 layer structure high-density PCB
e777乐彩线路检测Size standard 160 × 100mm (customizable)
Combination of high-density pin sockets and Phoenix terminals for connectors
Typical Applications
e777乐彩线路检测Remote signal transmission of sensors/actuators for semiconductor etching machines and deposition equipment
e777乐彩线路检测Distribution of control signals for vacuum systems and ion implantation machines
Remote I/O Expansion of Industrial Automation Production Lines
Multi channel signal conversion for testing system
AMAT Applied Materials 0100-09126远程配线板 e777乐彩线路检测
