GE   193X706AAG02放大器卡

1.产 品 资 料 介 绍：

中文资料：

GE 193X706AAG02 放大器卡技术资料

产品型号：193X706AAG02
产品名称：放大器卡（Amplifier Card）
制造商：General Electric (GE)
系列：193X 系列工业控制板卡
功能分类：信号放大与增益调节模块（Signal Amplification and Gain Adjustment）
应用领域：工业自动化系统、数据采集、过程控制等

一、产品功能

e777乐彩线路检测GE 193X706AAG02 放大器卡是一款用于提高输入信号幅度并提供信号增益的模块。它将输入的微弱信号放大，以便能够被系统下游的其他设备或控制单元所接受。该卡广泛应用于需要信号增益和放大的系统中，如工业自动化控制、传感器信号处理、数据采集系统等。

主要功能：

• 输入信号放大：将低幅度的模拟信号进行放大，以满足下游设备的输入要求。

• 增益调节e777乐彩线路检测：提供不同的增益选项，适应多种输入信号条件。

• 信号稳定性：提高信号的稳定性，减少噪声干扰，确保精确控制。

• 电气隔离：为防止高电压或电气噪声干扰，提供输入与输出的电气隔离。

二、主要技术参数

英文资料：

GE 193X706AAG02 amplifier card technical data

Product model: 193X706AAG02

Product Name: Amplifier Card

Manufacturer: General Electric (GE)

e777乐彩线路检测Series: 193X series industrial control board

Function classification: Signal Amplification and Gain Adjustment Module

e777乐彩线路检测Application areas: Industrial automation systems, data acquisition, process control, etc

e777乐彩线路检测1、 Product Features

e777乐彩线路检测The GE 193X706AAG02 amplifier card is a module used to increase input signal amplitude and provide signal gain. It amplifies the weak input signal so that it can be accepted by other downstream devices or control units in the system. This card is widely used in systems that require signal gain and amplification, such as industrial automation control, sensor signal processing, data acquisition systems, etc.

Main functions:

e777乐彩线路检测Input signal amplification: Amplify low amplitude analog signals to meet the input requirements of downstream devices.

Gain adjustment: Provides different gain options to adapt to various input signal conditions.

Signal stability: Improve signal stability, reduce noise interference, and ensure precise control.

Electrical isolation: To prevent interference from high voltage or electrical noise, provide electrical isolation between input and output.

2、 Main technical parameters

e777乐彩线路检测Parameter item description

e777乐彩线路检测The input signal type is analog signal, such as voltage, current signal, commonly 0-10V, 4-20mA, etc

e777乐彩线路检测The output signal type is an amplified analog signal, usually ranging from 0-10V or other standard voltage outputs

e777乐彩线路检测Amplification gain adjustable gain, usually providing multiple gain setting options such as 1x, 10x, 100x, etc

Input/output isolation provides electrical isolation between input and output, preventing the transmission of electrical noise and interference

Power requirement ± 15V DC or 24V DC, according to the system power standard

Signal bandwidth is suitable for broadband signal amplification in industrial applications, ensuring accurate signal transmission

e777乐彩线路检测The working temperature range is usually -40 ° C to+85 ° C, suitable for various industrial environments

Installation method plug-in card, compatible with GE 193X series control rack or control system framework

The interface type generally adopts terminal connection or metal pin interface, which is used to connect external sensors and devices

e777乐彩线路检测Card size standard GE plug-in module size, in accordance with the standard format of 193X series cards

2.产      品      展      示
