GE   193X456AAG03继电器卡

1.产 品 资 料 介 绍：

中文资料：

产品信息

• 产品型号e777乐彩线路检测：193X456AAG03

• 产品名称：继电器卡（Relay Card）

• 制造商：General Electric (GE)

• 产品系列e777乐彩线路检测：193X 控制系统模块

产品功能

193X456AAG03 是 GE 193X 系列控制系统中的一块 继电器控制卡e777乐彩线路检测，其核心功能是通过逻辑控制信号，驱动板载继电器，实现高低压电路之间的隔离与控制。主要应用于驱动命令、电路切换、报警输出等。

技术特点

典型应用场景

• 控制大功率电接触器、断路器、励磁电路等

• 作为执行逻辑的物理输出单元

• 发出报警、状态反馈信号

• e777乐彩线路检测实现远程电气操作或系统联动控制

维护与故障排查建议

• 继电器触点粘连：使用万用表检测触点是否机械卡滞

• 信号不响应：检查控制信号输入端是否正常

• 电磁线圈损坏e777乐彩线路检测：检测继电器线圈电阻是否正常（开路/短路）

• 接插件松动：检查插槽及连接排线是否牢靠

英文资料：

PRODUCT INFORMATION

Product model: 193X456AAG03

e777乐彩线路检测Product Name: Relay Card

manufacturer: General Electric (GE)

e777乐彩线路检测Product Series: 193X Control System Module

e777乐彩线路检测PRODUCT FUNCTION

e777乐彩线路检测193X456AAG03 is a relay control card in the GE 193X series control system. Its core function is to drive onboard relays through logic control signals, achieving isolation and control between high and low voltage circuits. Mainly used for driving commands, circuit switching, alarm output, etc.

FEATURES

e777乐彩线路检测Project Description

e777乐彩线路检测The control mode is triggered by the logic board of the control system (such as CPU, driver card) issuing a trigger signal

Output type: Electrical relay contact output (normally open/normally closed)

e777乐彩线路检测Multiple channels (usually 4-8 relays)

Electrical isolation relay action provides input and output electrical isolation

Installation structure plug-in card, installed in the standard rack of 193X system

Typical application scenarios

e777乐彩线路检测Control high-power electrical contactors, circuit breakers, excitation circuits, etc

As a physical output unit for executing logic

Send out alarm and status feedback signals

Realize remote electrical operation or system linkage control

e777乐彩线路检测Maintenance and troubleshooting suggestions

Relay contact adhesion: Use a multimeter to check if the contacts are mechanically stuck

e777乐彩线路检测Signal not responding: Check if the control signal input terminal is normal

e777乐彩线路检测Electromagnetic coil damage: Check if the resistance of the relay coil is normal (open circuit/short circuit)

Loose connectors: Check if the slots and connecting cables are secure

2.产      品      展      示
